NOTICE:
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap ...
1. Before using Underground Mining Locomotive, the inspection and preparation should observe whether there are obstacles on the front track, check the wear of the brake shoes, and whether the gap between the brake shoes and the wheel tread meets the specified values.
2. Underground Mining Locomotive Start and Operation
(1) Insert the pin connector plug of the power supply device into the socket according to its polarity and connect it properly. Move the direction handle to the position where the Underground Mining Locomotive is about to travel, turn on the light switch, and then rotate the brake handwheel counterclockwise to release the handwheel brake. Ring the alarm, issue instructions, and prepare to drive.
(2) Operate the speed control handle from the "0" position to the "closing" position and then to the "traction induced motion" position. Continue to move forward to 120 °, and the locomotive is running at the voltage regulating position; When the handle is moved from 120 ° to the end position (approximately 150 °), the locomotive is in full pressure operation.
3. When low-speed operation is required, the handle can be pulled back from the full speed position to the appropriate speed position. The driver can control the handle at a speed between 35 ° and 150 ° in the traction position according to actual needs.
4. When the Underground Mining Locomotive is about to stop running, the speed control handle should first be returned to the zero position, and then the handwheel should be mechanically braked. Rotate the handwheel clockwise until it cannot rotate, causing the brake shoe to lock the wheel.
5. When the driver leaves the Underground Mining Locomotive, the locomotive should be in a braking state (the next boarding operation should first release the brake). Return the main and auxiliary handles to the "0" position, take out the reversing handle and take it with you.
6. When the Underground Mining Locomotive is running, it is not allowed to get out of the Underground Mining Locomotive at will or let others control it at will. When it is necessary to leave the Underground Mining Locomotive temporarily, it is necessary to cut off the power of all motors, brake the electric locomotive with the hand wheel braking system, remove the reversing handle and take it away. But the lights should still be turned on.
