Introduction of JMY600 Diesel Hydraulic Mining Locomotive
About JMY600 Diesel Hydraulic Mining Locomotive , the diesel engine shall at least be compliant with EU-RL, Directive 2004/26/EC, Stage III or US EPA Tier 3 requirements for “off road” diesel engines. The concentration of toxic emissions in the neat exhaust of the diesel engine must not exceed the specified limits as stipulated in the above requirements.
Main Parameter of JMY600 Diesel Hydraulic Mining Locomotive
|
Overall dimension (LxWxH)
|
10,900 x 2,700 x 3,680 mm.
|
|
Power
|
551.5 KW
|
|
Construction Speed
|
64 Km/h
|
|
Maximum speed in CM
|
50 Km/h
|
|
Locomotive service weight
|
56+/- 3% Ton
|
|
Axle load
|
14+2%Ton
|
|
Wheel Diameter
|
Dia. 850 +/- 5mm
|
|
Track gauge distance
|
1435mm
|
|
Minimum passing curve
|
80mm @ max. speed of 10 km/h.
|
|
Coupler type
|
Scharfenberg 35
|
|
Coupler height
|
770 +/- 5mm
|
|
Brake type
|
JZ-7 Air Brake System.
|
Hydraulic Transmission Box
|
Type
|
A969 FI 2.2 (B)
|
|
Type of torque converter
|
B45, B85.
|
|
Gear shifting mode
|
Automatic or Manual
|
|
Battery unit
|
Type GNC 170 high power nickel-cadmium alkaline battery, 170 AH. One set 22 units.
|
PHOTOS OF JMY600 Diesel Hydraulic Mining Locomotive
PHOTOS OF JMY600 Diesel Hydraulic Mining Locomotive
